kingsmill earthing tinned stranded copper cable

Stranded Copper Cable (Tinned)

Stranded Copper Cable (Tinned) is used where extra corrosion protection is required.

Material:

Tinned soft drawn stranded copper cable

Standard:

BS:EN 60228



To request a quotation, select the version you require using the drop down options below.

Clear
Categories: , , Part: BSCWxxx/T
CSA (mm²)
NOMINAL DIAMETER (mm)
STRANDING No./DIA (mm)**
WEIGHT (kg/m)
PART NO.
16
5.10
7 / 1.70
0.15
BSCW016/T
25
6.42
7 / 2.14
0.23
BSCW025/T
35
7.56
7 / 2.52
0.32
BSCW035/T
50
8.90
19 / 1.78
0.43
BSCW050/T
70
10.70
19 / 2.14
0.62
BSCW070/T
95
12.60
19 / 2.52
0.86
BSCW095/T
120
14.21
37 / 2.03
1.09
BSCW120/T
150
15.75
37 / 2.25
1.33
BSCW150/T
185
17.64
37 / 2.52
1.67
BSCW185/T
240
20.25
61 / 2.25
2.20
BSCW240/T
300
22.68
61 / 2.52
2.76
BSCW300/T
400
25.65
61 / 2.85
3.53
BSCW400/T
